xPortalNet HS v2.0
xPortalNet HS v2.0
xPortalNet HS v2.0
DesFire High Security System Software supports full DesFire 64-bit card system with 20 digits Card Serial Number (CSN) and Card ID (CID).
xPortalNet HS v2.0Features
- 20 Digits (Full DesFire 64-bit CSN and Card ID)
Higher Security by recording both DesFire Card Serial Number (CSN) and the Card ID (CID), with 20 digits each. This captures the Full 64-bit number. The system will track the CID with the CSN to ensure that the the card matches the full record. Identification not just by CSN. - DesFire Security Profile Configuration
Full support of DesFire Security Profile Configuration in the software. This allows the user to have maximum control of the security key setting and change it whenever they want to. Programming of the cards can be done through the desktop card programming unit. - Alarm Monitoring & Lift Controller
Supports up to 512 inputs / 256 outputs / 256 LED Mimic outputs with event programming. User notification can be achieved through client applications, email and SMS for maximum flexibility.
Control of up to 96 floors per lift. Support multiple lobby implementations for large scale projects. - CCTV Integration
Tightly integrated to MicroEngine’s line of DVDs for viewing and capturing purposes. DVDs and CCTVs will be shown on the floor plan to ease identification and management. - Visitor Management System (VMS)
Integrated VMS module to enable control and recording of visitors. Optional VMS module to generate QR Code as the Visitor ID and send to the visitor’s mobile phone. Optional VMS kiosk system for self-service visitor registration and sign in. - Floor Plan
Comprehensive floor plan control to enable easy viewing and control device of status. - Time Attendance
Comprehensive configurations to allow the maximum flexibility in shift and allowance settings. Supports multiple and overnight shifts. Allow for further customisations to suit customer’s requirements. - Web Server Support
IIS8.5 with ASP.NET allows user to login using the web browser from any part of the world.
FeaturesConnectivity SetupOrdering InformationPC RequirementsDocumentation
| No | Item | Features |
| 1. | Client Server | Yes. Up to 20 Clients. |
| 2. | System | Door Access/Lift Access/Car Park/Alarm Monitoring/Guard Tour |
| 3. | Card Holder | 100,000 (20 digits) |
| 4. | No. of Door / Readers | 1024 Doors / 2048 Readers |
| 5. | No. of Inputs / Outputs | 1024 Inputs / 1024 Outputs |
| 6. | Time Set / Time Zone | 1024 |
| 7. | System Users | Unlimited |
| 8. | Software Access Control | Yes. User Configurable Command Level Access Control. |
| 9. | Floor Plan System | Yes. Dynamic & with Camera Icon. |
| 10. | Database Supported | MS SQL Server / Oracle |
| 11. | OS | Microsoft Windows 2008/2012 Server 64-bit |
| 12. | Microsoft .Net | Yes |
| 13. | Communication Supported | LAN / RS485 |
| 14. | Controller Supported | ⦁ XP-GLS5000 – Encrypted IP DesFire 5 Door Controller ⦁ XP-GLS130 – Encrypted IP DesFire 1 Door Controller ⦁ XP-GLS300 – Encrypted IP DesFire 1 Door Controller |
| 15. | Time Attendance | Yes. Non-Overnight. |
| 16. | Real Time Export | Yes. User Configurable. |
| 17. | Model | xPortalNet HS Lite, xPortalNet HS Standard, xPortalNet HS Pro, xPortalNet HS PS |
* The feature listed here are for the software only. It depends on the choice of the hardware system such as controller, I/O board, readers and computer system for it to work. Kindly contact our representatives for further clarifications.
| No | Product Code | Description |
| 1. | XP-GLS5000 | Encrypted IP DesFire 5 Door Controller |
| 2. | XP-SNet-E5DS | 5 Door GLS Extension Board |
| 3. | XP-SNet-E32R | 32 Relay Output Extension Board |
| 4. | XP-SNet-E248S | 24 Supervised Input & 8 Relay Output Extension Board |
| 5. | XP-GLS130 | Encrypted IP DesFire 1 Door Controller |
| 6. | XP-GLS300 | Encrypted IP DesFire 1 Door Controller |
| 7. | PiO-S248 | 24 Supervised Input & 8 Relay Output Alarm Controller |
| 8. | PiO-R24 | 24 Relay Output Controller |
| 9. | Pio-L32 | 32 LED Driver Controller (for Mimic Panel) |
| 10. | MK801 | Door Interface |
| 11. | Plato-DF800S | DesFire Reader |
| 12. | Plato-DF800KLS | DesFire Reader with Touch Sense Keypad & Graphic LCD |
| 13. | xPortalNet HS Lite | xPortalNet HS Lite Software c/w 1 USB Key (Special Edition) 3 Client Version, Up to 200 connections Runs on Microsoft SQL Server Database |
| 14. | xPortalNet HS Std | xPortalNet HS Standard Software c/w 1 USB Key 3 Client Version, Up to 200 connections With Data Partitioning |
| 15. | xPortalNet HS / RC | xPortalNet HS Remote Communication Gateway Add 100 connections capacity to xPortalNet Load balancing for more robust operation Runs on Windows Server 2008/2012 64 bit |
Server
| No | System | Requirements |
| 1. | CPU (Minimum) | Xeon E5506 2.13Ghz |
| 2. | RAM (Minimum) | 16 GB |
| 3. | OS | Microsoft Windows 2008 / 2012 Server 64 bit |
| 4. | Microsoft.Net Framework v2.0 | Yes |
| 5. | Microsoft SQL Server 2008 | Yes (at least standard version) |
| 6. | Ethernet | Yes |
| 7. | Serial Port | Yes |
| 8. | Display (1024 x 768 x 16 bit colours) |
Yes |
| 9. | Mouse / Keyboard | Yes |
| 10. | UPS (recommended) | Yes |
| 11. | Hard disk (minimum free space) | 500 GB |
| 12. | USB Port | Required for Software Key |
PC Client
| No | System | Requirements |
| 1. | CPU (Recommended) | Intel Core 2 Duo E8400, 3.0 GHz or higher |
| 2. | RAM (minimum) | 4 GB |
| 3. | OS | Microsoft Win 7/ Win 10/ Win Server 64 bit |
| 4. | Microsoft .Net Framework v2.0 | Yes |
| 5. | Ethernet | Yes |
| 6. | USB Port / Serial Port | Optional (Required for USB desktop reader / serial port card reader) |
| 7. | Display (1024 x 768 x 16 bit colours) |
Yes. Higher Resolution Required for CCTV. |
| 8. | Mouse / Keyboard | Yes |
| 9. | Hard Disk (Free Space) | 50GB |
| No | Documentation |
| 1. |  Product Brochure: xPortalNet HS |
