RDPRX/ RDMFX

RDPRX/ RDMFX

XP-RDPRX
(Proximity Card Reader)

  • Simple
  • Reliable
  • Weather proof

XP-RDMFX
(Mifare Contactless Smart Card Reader)

  • Simple
  • Reliable


FeaturesConfiguration DiagramFAQ
No Features RDPRX RDMFX
1. Connectivity ABA T2
2. Reader type EM Proximity ISO14443 A/B / Mifare
3. Card Digits 6
4. Reading range Max. 7cm Max. 3cm
5. LED indication Green and Red
6. Buzzer Yes
7. Dimension (HxWxD) 100mm x 53mm x 20mm 125mm x 94mm x 30 mm
8. Epoxy Yes No
9. Weather proof Yes No
10. Casing Material ABS plastic
11. Input voltage 12VDC
12. Current (Typical) 150mA at 12VDC
13. Operating Temperature 0-50◦C

Configuration Diagram for Door Access Application

Configuration Diagram for Car Park Application

FAQ

1. I have purchased XP-SR200K and I need to…
2. I have installed XP-RDPRX at my site, but how do I configure the controller
